Add-on options
Add-on inspection options and capabilities
PVH- Plugged Via Holes Inspection
PVH option is an add-on functionality for selected CIMS AOI models enabling inspection of plugged via holes down to 75 microns in diameter. This new system further extends CIMS line of products an options for drill inspection applications.
3D Metrology
3D metrology enable accurate three dimensional measurements of individual elements of a PCB circuit.
CIMS offers two types of 3D metrology: +3DH and +3DP.
2D Metrology
2D metrology enable accurate two dimensional measurements of individual elements of a PCB circuit.
CIMS offers two types of 2D metrology: +2CD and +2DM.
LDI
CIMS LDI is a laser drill inspection option designed for HDI PCB and IC Substrates.
It is capable of scanning both pre- and post-plating laser vias as well as conformal masks of all sizes.
Fi – Final Inspection
Fi (Final Inspection) option allows inspecting of finished boards.
It is supplied as an add-on option suitable for all CIMS Phoenix models extending their capabilities to final inspection.
